BOEING 737 MCP
€55,00 – €360,00
MCP (Mode Control Panel) for your cockpit!
- Simple. Connect USB and Play
- Full backlight
- High-quality laser-cut and engrave
- All parts, Power adapter, USB cables, user guide, and the extension will be sent with your order.
Our finish products are compatible with these simulations programs: P3D ( PMDG ), X-Plane11 (ZIBO).
Finished Product:
-Compatible P3D, X-Plane11
-Simple. Plug and Play
-Interface with Mobiflight, Air Manager, etc.
-A/P Disengage controlled with 2 parallel toggle switch
-Full backlight
-Buttons with LED
-Power adapter 220V-5V European type added
Front Plate:
-Painted with RAL7011
-3mm Plexiglass
-Laser-cut and engraved
-Buttons are painted with black and laser engraved
Needed components (for DIY):
- 109 1206 SMD LED (amber)
- 3 1206 SMD Capacitor Aluminum; 100uF
- 3 1206 SMD Capacitor Ceramic; 10uF
- 22 White 0.36 inch 1 Bit 7 Segment LED Display Common Cathode
- 133 1206 SMD Resistor; 200 ohms
- 2 Switch Toggle; ON None ON
- 5 Rotary Encoder 12mm
- 3 MAX7219CWGT to control 7-Segment
- 3 Male Box Header 2.54mm 6 Pin
- 1 Male Box Header 2.54mm 16 Pin
- 17 Tact Switch LED, Thru-Hole 12x12mm
- 1 Header 2.54mm 6 Pin
-Components are soldered to the PCB and tested.
Only PCB:
-Perfectly fit for the components
Options: Only PCB / Assembled PCB / Finish Product
| Weight | N/A |
|---|---|
| Option | Finish Product, Assembled PCB, Front Plate, Only PCB |
