How to connect ATC Radio Module Mobiflight? (MSFS2020/XP11/P3D/FSX)

Everything you need to run the ATC Radio Module via Mobiflight is on this blog page.

Steps:

1. Install Driver
2. Install Mobiflight
3. Download Mapping/Config File:
   • Prepar3D PMDG 737-800NGX (soon)
     X-Plane Zibo737 (updated 04.01.2023)
     X-Plane12 Zibo737 (updated 25.04.2023)
     MSFS2020 PMDG737 (updated 02.11.2022)
4. Run Mobiflight
5. Load the Config File into Mobiflight
6. Ready to go!

If you order before 17.09.2022, please note that:

The ATC you have is configurated to run via XPLDirect with X-Plane 11 Zibo737. Update the firmware by following the steps;
1) Download the Uploader
2) Download the Firmware and CPT Module Config File
3) Close all applications and be sure Mobiflight is not running in the background
4) Connect ATC via USB
5) Extract Uploader
6) Move the Firmware file(mobiflight_uno_9.0.0.hex) into Uploader
7) Run Xloader.exe
8) Click the file selection button
9) Select the Firmware File
10) Select the device as EFIS/NAV/COMM/ATC/ADF V1
11)Select the Com Port which is the ATC connected
12) Click the Upload button.
If Xloader still says “Uploading” after 2 min.;
12.1) Disconnect the USB cable and then connect it
12.2) Select the device as EFIS/NAV/COMM/ATC/ADF V2
12.3) Check the Com Port is the USB port connected to ATC.
12.4) Click the Upload button

13) Run Mobiflight
14) Click Mobiflight Modules
15) Select the module (ATC) according to the Com Port
16) Load the Module Config File into the Module
17) Restart Mobiflight

If any help is needed, feel free to contact us via Facebook, Discord or e-mail.

Best Regards,
M. Yasar Kaya
